Universal Horn Turn Signal Light On/Off Switch for 7/8″ Handlebar Dirt Bike Scooter ATV Motorcycle
Universal Horn Turn Signal Light On/Off Switch for 7/8″ Handlebar Dirt Bike Scooter ATV Motorcycle
Universal Horn Turn Signal Light On/Off Switch for 7/8″ Handlebar Dirt Bike Scooter ATV Motorcycle
7/8″ 12V Head Light Switch Horn Turn Signal On/Off Motorcycle ATV Scooter
Easy to mount over your existing clutch lever perch to save space
Fit most of motorcycles, ATVs, Dirt bikes, Scooters,custom with 7/8″(22mm) diameter handlebars
Material : Plastic , Copper Wire. Metal Bracket Diameter:22mm 7/8 inch. Overall wire length:100cm
Green Button: Horn , Red Button: Headlight , Black Button: Turn Signal . Voltage:12v DC
This Switch has the following features it has a button for your Horn, it has left and right turn signals, and a On/Off button for your lights
Product description
Motorcycle Horn Turn Signal Light Switch For 7/8″ Handlebar Bike Scooter On/Off
WIRING DIAGRAM:
2*White = Horn
2*Blue = Head Light??red bottom??
Yellow = Left Turn Signal
Green = Right Turn Signal
Red = Flaser *Ground* for Turn Signal Lights
Package Contents: 1 x Handlebar Light Turn Signal Light Horn On/Off Switch
