Premium Quality Replacement Part
Rear Upper Inner A-Arm Bushing Kit
For Polaris Models:
Ranger 1000 2018-2022
A-Arm Part Number:
Rear Upper Left 1022800-458 1022800-647
Rear Upper Right 1022801-458 1022801-647
Order Includes:
2 x Pivot Shaft | 5139966
4 x Bushing | 5452233
2 x Bolt | 7519043
2 x Nut | 7547333
2 x Washer | 7556153
Dimensions & Measurements :
Pivot Shaft
Length:51mm
Inner Diameter:10mm
Outer Diameter:16mm
Bushing
Outer Diameter:26mm
Inner Diameter:16.5mm
Height:15.5mm
Nut
M10x1.25
Part Number :
Pivot Shaft | 5139966
Bushing | 5452233
Bolt | 7519043
Nut | 7547333
Washer | 7556153
**
