Premium Quality Replacement PartRear Upper Outer Left & Right Control Arm Bushing KitFor Polaris Models:Sportsman XP 550 HD 2013-2014Control Arm Part Number:Rear Upper Left 1025619-067 1017216-067Rear Upper Right 1025620-067 1017217-067 Note: Installs On Location (D) In Second PictureOrder Includes:2x Bolt : 7518675Height : 140mmThread size : M10X1.52x Nut : 7547313Height : 13mmInner Diameter : 8.5mmOuter Diameter : 21.5mmThread Size : M10X1.52x Pivot Shaft : 5137590 5135501Length : 105mmInner Diameter : 10mmOuter Diameter : 16mm4x Bushing : 5439874 5436505 5436832Height : 30mmInner Diameter : 16mmOuter Diameter : 31mm**
