Rear Upper Control Arm Bushing Kit For Polaris Sportsman 850 Touring 2011-14
Rear Upper Control Arm Bushing Kit For Polaris Sportsman 850 Touring 2011-14 - Image 2
Rear Upper Control Arm Bushing Kit For Polaris Sportsman 850 Touring 2011-14 - Image 3
Rear Upper Control Arm Bushing Kit For Polaris Sportsman 850 Touring 2011-14 - Image 4

Rear Upper Control Arm Bushing Kit For Polaris Sportsman 850 Touring 2011-14

SKU ChT.03862 Category Tags , , , ,

Rear Upper Control Arm Bushing Kit For Polaris Sportsman 850 Touring 2011-14

Premium Quality Replacement PartRear Upper Outer Left or Right Control Arm Bushing KitFor Polaris Models:Sportsman 850 Touring 2011-2014Control Arm Part Number:Rear Upper Left 1025619-067 1017216-067 1025619-385 1017216-385Rear Upper Right 1025620-067 1017217-067 1025620-385 1017217-385Note: Installs On Location (D) In Second PictureOrder Includes:1x Bolt : 7518675Height : 140mmThread size : M10X1.51x Nut : 7547313Height : 13mmInner Diameter : 8.5mmOuter Diameter : 21.5mmThread Size : M10X1.51x Pivot Shaft : 5137590 5135501Length : 105mmInner Diameter : 10mmOuter Diameter : 16mm2x Bushing : 5439874 5436505 5436832Height : 30mmInner Diameter : 16mmOuter Diameter : 31mm**
