Rear Differential W/ Propeller Drive Shaft For Yamaha Grizzly 660 YFM660F 03-08

SKU LJQ.04779 5KM-46101-12-00, 5KM-46101-11-00, 5KM-46101-10-00, 5KM-46101-00-00, 5KM461011200, 5KM461011100, 5KM461011000, 5KM461010000, 5KM-46172-00-00, 5KM461720000 Category Tag

Rear Differential W/ Propeller Drive Shaft For Yamaha Grizzly 660 YFM660F 03-08

Premium
Quality Replacement Part
Rear Differential with Propeller Drive Shaft
For Yamaha Models:
Grizzly 660 Yfm660f 4×4 2003-2004
Grizzly 660 Yfm660f 4×4 Limited Edition 2003-2004
Grizzly 660 Yfm660fa 4×4 2005-2008
Grizzly 660 Yfm660fah 4×4 Outdoorsman Edition 2006
Grizzly 660 Yfm660fase 4×4 Special Edition 2005-2006
Grizzly 660 Yfm660fg 4×4 2007-2008
Grizzly 660 Yfm660fgh 4×4 Hunter Edition 2007-2008
Grizzly 660 Yfm660fh 4×4 Hardwoods Hunter Edition 2003-2006
Grizzly 660 Yfm660fhw 4×4 Wetland Hunter Edition 2003-2005
Order Includes:
1x Rear Differential: 5KM-46101-12-00 5KM-46101-11-00 5KM-46101-10-00 5KM-46101-00-00
Length: 282 mm – 11.1 in
Width: 189.5 mm – 7.46 in
Height: 143.8 mm – 5.66 in
1x Propeller Drive Shaft: 5KM-46172-00-00
Length: 232 mm – 9.13 in
