This is a set of new CV axles & wheel bearings for a Polaris UTV.
pair of
They fit REAR, LEFT & RIGHT on the following models:
2007-2009 Ranger 500 2×4/4×4 (built after Aug 28 2006)
2007-2009 4×4 Ranger 700/Crew 700 (built after Aug 28 2006)
2007-2009 4×4 Ranger XP 700/XP 700 LE (built after Aug 28 2006)
2010-2017 6×6 Ranger 800
*Made as an OE replacement, and not intended for lifted/ modified vehicles
Product features:
Stronger than OEM, 4340 chromoly steel axle bars
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear & puncture resistance
High speed bearings manufactured for long life
Double lip seals made to keep grease in and dirt out
Inboard CV joint spline count: Left – 27/29, Right – 27
Outboard CV joint spline count: Left – 26, Right – 26
Compressed overall axle length: Left – 705 mm, Right – 660 mm
Replaces OEM # (left) 2204857, 1332502, 1332575, (right) 2204858, 1332503, 1332576, & (bearing) 3514635 3585502
