Primary Drive Clutch Kit for Polaris General 1000 Deluxe EPS 2018-2023 / 1323241 (For: Polaris)
Primary Drive Clutch Kit for Polaris General 1000 Deluxe EPS 2018-2023 / 1323241 (For: Polaris)
Primary Drive Clutch Kit for Polaris General 1000 Deluxe EPS 2018-2023 / 1323241 (For: Polaris)
Premium Quality Replacement Part
Primary Drive Clutch Rebuild Kit
For Polaris Models:General 1000 Deluxe EPS 2018-2023
Order Includes:3x Weight: | 5633496 (29-66)1x Spring: | 70442631x Needle Bearing (Non EBS) | 35146093x Roller: | 13216223x Roller Pin: | 50204226x Roller Washer: | 5438247 5430702 54309456x Button: | 54509403x Shoulder Bolt: | 75122663x Nut 7541906: | 32353201x Jam Nut: | 75474982x Washer: | 75563351x DU Bushing: | 35144921x Bushing Cover: | 35765101x Spacer: | 56328942x Washer: | 5438963
Dimensions & Measurements:
Needle Bearing
Item Height: 44.30 mm | 1.74″Item Outer Diameter: 31.70 mm | 1.24
Clutch Spring
Item Length: 86 mm | 3.38″Item Width: 50 mm | 1.97″
Clutch Weight (29-66)
Item Length: 55 mm | 2.16″Item Thickness: 13.30 mm | 0.52″
Hote:
The kit includes Non EBC Bearing
**
