Product Description:
Premium quality replacement part. Front upper and lower left right A-arm bushing ball joint kit.
Includes:
8 x Pivot Shaft (5135270):
– Length: 63.7 mm / 2.50 in
– Inner diameter: 10.2 mm / 0.40 in
– Outer diameter: 16 mm / 0.62 in
16 x Short Bushing (5436798):
– Length: 20.5 mm / 0.8 in
– Inner diameter: 15.5 mm / 0.6 in
– Outer diameter: 31 mm / 1.2 in
8 x Bolt (7518466):
– Length: 94 mm / 3.7 in
– Across corners: 15 mm / 0.59 in
– Thread length: 29 mm / 1.14 in
– Thread size: M10 x 1.5
8 x Nut (7547313):
– Height: 13 mm / 0.51 in
– Inner diameter: 8.5 mm / 0.33 in
– Outer diameter: 21.5 mm / 0.84 in
– Thread size: M10 x 1.5
4x Ball Joints (7061220, 7082507, 7081924, 7081665, 7081859, 7081991, 7061187, 7081505, 7081580, 7081666):
– Height: 65.5 mm / 2.57 in
– Upper diameter: 16 mm / 0.63 in
– Lower diameter: 31 mm / 1.22 in
A-Arm Part Numbers for Reference:
– Front upper left: 1015125-067, 1025617-067, 1017260-067
– Front upper right: 1015126-067, 1025618-067, 1017261-067
– Front lower left: 1016737-067, 1019810-067, 1017156-067
– Front lower right: 1016738-067, 1019811-067, 1017157-067
– Knuckle left: 2204254
– Knuckle right: 2204255
Fits / Compatible Models (Polaris):
– Sportsman XP 550 Touring (2009)
– Sportsman XP 850 EFI EPS (2009)
