Front Axle for Arctic Cat Prowler 550 650 700 1000 4×4 1502-348

Product categories
Product tags
air filter axle bearing bracket brake disc brake disk brake pads bushing bushing block carburetor car lamp car light centrifugal clutch clutch clutch parts disc-brake disc brakes disk brake front fork gasket headphone headset holder ignition coil ignition spark booster jump-spark coil Lamps Lift Kit Lights liner bushing lining lowering kit protective cover seal shaft shock absorber sleeve bushing spark coil sparking coil switch tire tool tyre washer wheel hub
Front Axle for Arctic Cat Prowler 550 650 700 1000 4x4 1502-348
Front Axle for Arctic Cat Prowler 550 650 700 1000 4x4 1502-348 - Image 2
Front Axle for Arctic Cat Prowler 550 650 700 1000 4x4 1502-348 - Image 3

Front Axle for Arctic Cat Prowler 550 650 700 1000 4×4 1502-348

SKU Z.20608 1502-939, 0502-734 Category Tags ,

Front Axle for Arctic Cat Prowler 550 650 700 1000 4×4 1502-348

This is a new Front CV axle for a Honda ATV.It will fit front left (driver side) on the following models:2011-2015 … Prowler HDX 7002009-2014 … Prowler XTZ 1000It will fit front right (passenger side) on the following models:2009-2014 … Prowler 5502006-2009 … Prowler 6502008-2014 … Prowler XT/XTX 700*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM chromoly forged steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear & puncture resistance
Inboard CV joint spline count: 24
Outboard CV joint spline count: 27
Compressed overall axle length: 662 mm
Replaces Arctic Cat OEM # 1502-939, 0502-734, 1502-348, 1502-802
