This is a new Front CV axle & wheel bearing for a Honda ATV.They fit front right (passenger side) on the following models:2011-2015 … Prowler HDX 7002009-2014 … Prowler XTZ 1000They fit front left (driver side) on the following models:2009-2014 … Prowler 5502006-2009 … Prowler 6502008-2014 … Prowler XT/XTX 700*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM chromoly forged steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear and puncture resistance
High speed bearing manufactured for long life
Double lip seal made to keep grease in and dirt & water out
Inboard CV joint spline count: 24
Outboard CV joint spline count: 27
Compressed overall axle length: 695 mm
Replaces Arctic Cat OEM # (axle) 1502-940, 0502-733, 1502-347, 1502-803, (bearing) 1402-027, 1402-809
