Fitment:
ALL CAN AM MAVERICKS, COMMANDERS, and DEFENDERS
??This Item is for the WINCH Switch with AMBER ORANGE led backlight PLUS the matching receiver block.??
Working princinple:
This switch matches the Can-AM OEM switches. It has the raised dimples and the white face with AMBER = ORANGE backlight. It includes instructions on how to make it act like the BRP OEM switches ( lights up amber when the key is turned on)
Descriptions:
The receiver block has pre-installed jumpers / pigtails and each terminal is crimped and soldered. It makes installation a lot easier.
Dual orange LED back lit switch have raised dimples on the switch face.
A back lit panel that illuminates when the key is on and an indicator light the illuminates when the switch is turned to the on position.
O-Rings on the LED and the center shaft to seal out water, dust, and debris.
Rated 20A 12V. There are no rear barriers between terminals. Standard 1/4″ female terminals can be used.
