Clutch Driven pulley For CFmoto CF188 CF500 X500 500CC chun feng ATV UTV Secondary Clutch Sheave Driven Pulley Wheel CDL-CF500 CF188-05200

This is CF500 Driven Clutch Only for the 4 stroke liquid cooled CFmoto CF500 CF188 engine.
CF Moto 500cc ATV listed part number is 0180-052000 with old part number listed as CF188-052000 Product Description
CF188-052006 0180-052006 Nut CF188-052004 0180-052004 Secondary Spring Socket CF188-052003 0180-052003 Pressure Spring CF188-052002 0180-052002 Spacer CF188-052203 0180-052203 Oil Seal 50X58X4 CF188-052204 0180-052204 O-Ring 56.5X1.9 CF188-052200 0180-052200 Secondary Loose Pulley Assy. CF188-052005 0180-052005 Guide Pin CF188-052001 0180-052001 Guide Ring CF188-052100 0180-052100 Secondary Tight Pulley Assy. If you have large order,You can ask CF188 Parts List and send us the parts code with QTY to Inquiry whole sale price by e-mail.
