Carburetor for Suzuki LT-K400 2003-2007 replaces OEMs 13200-38FBV 13200-07G01
Carburetor for Suzuki LT-K400 2003-2007 replaces OEMs 13200-38FBV 13200-07G01 - Image 2
Carburetor for Suzuki LT-K400 2003-2007 replaces OEMs 13200-38FBV 13200-07G01 - Image 3
Carburetor for Suzuki LT-K400 2003-2007 replaces OEMs 13200-38FBV 13200-07G01 - Image 4
Carburetor for Suzuki LT-K400 2003-2007 replaces OEMs 13200-38FBV 13200-07G01 - Image 5

Carburetor for Suzuki LT-K400 2003-2007 replaces OEMs 13200-38FBV 13200-07G01

SKU HYQ.12513 13200-07G01 13200-38FBV, 15003-S016 15003-S015 15003-S026 15003-S027, 3470-023 3470-031 3470-035, 5YT-14901-00-00 Category Tag

Carburetor for Suzuki LT-K400 2003-2007 replaces OEMs 13200-38FBV 13200-07G01

Package includes: 1x Carburetor 1x Throttle Base Cover 1x Throttle Base Rubber Gasket 1x Throttle Cable Clip 3x Base Cover Screw
Replaces OEM numbers: Kawasaki 15003-S016 15003-S015 15003-S026 15003-S027 Arctic Cat 3470-023 3470-031 3470-035 Suzuki 13200-07G01 13200-38FBV Yamaha 5YT-14901-00-00
This Aftermarket Carburetor is Compatible with Yamaha Raptor 350 YFM350 2004-2006 2014 Suzuki Quadsport LT-Z400 2003-2008 Suzuki LT-K400 2003-2007 Arctic Cat DVX400 2004-2008 Kawasaki KFX400 2003-2006 Kawasaki KSF400 2003-2005 Hisun TACTIC350 Hisun FORGE350
Specifications: Intake Inner Diameter: 36mm Intake Outer Diameter: 42mm Air Intake Outer Diameter: 58mm Air Intake Inner Diameter: 55mm Choke: Manual
